LG 75TC3D interactive whiteboard 190.5 cm (75\") Touchscreen 3840 x 2160

Unit :   0
Product ID :   7g8ucx9dnsn7r
Product State :   Brand New
Availability :   Out Of Stock
₦4,200,509 NGN
₦4,500,509NGN

More from ifexes multimedia

LG go-ex V 1.3 lte version
45,000 NGN
Samsung galaxy prem 3 series
95,000 NGN

#Discription___


The LG Interactive Digital Board (IDB) Series of products have been developed as a means of maximizing the effectiveness of meetings. The use of an IDB can also be extended beyond general business meeting rooms to various places such as fashion design offices, hospitals, military command centers, and architectural offices.

The LG IDB, powered by the IDB app, is the optimal solution to meet the requirements of meeting spaces. It helps facilitate a successful meeting by driving participants to freely submit their ideas on the screen using the intuitive touch and writing tools, as well as encouraging engagement thanks to easy connectivity and crisp graphics for high readability.

Experience Intuitive Touch and Writing1

Experience Intuitive Touch and Writing

• The advanced touch technology enables intuitive and precise touch responses.
• The embedded writing application is an optimized tool for writing directly onto the board.

Facilitate Efficient Collaboration Without a PC1

Facilitate Efficient Collaboration Without a PC

• The webOS 3.0+ smart platform makes it possible to collaborate without the need for a PC based on its high performance.
• The embedded IDB app enhances the optimized work-flow for efficient collaboration.


Ultra HD Picture Quality1

Ultra HD Picture Quality

• Ultra HD resolution presents details clearly and without distortion even in zoom mode, providing clear images.
• The LG IPS panel provides a wide viewing angle with accurate colors.

Precise Touch Performance

• Quick Response and Detailed Writing: The screen recognizes small touch points accurately and instantly shows the response to the touch point. This kind of accuracy and granularity means that users can use IDB both as a realistic handwriting tool and for detailed complex content such as drawings.

• Pen Thickness Variation: The thickness of the pen can be adapted to the user’s writing speed, even when using the passive pen. Lines or characters become bolder as the writing speed increases. This makes users feel as if they are writing on paper using their usual ballpoint pen.

• Multi-touch It allows multi-touches from 20 points (86TR3D) to 40 points (TC3D Series) so that multiple participants can simultaneously use touch features.

• Scratch-Resistant and Anti-Shatter Glass: The LG IDB has an advanced tempered screen coating to minimize scratches*. In addition, its anti-shatter glass is designed to minimize harm to the user, even in the event of an external shock.

• Intuitive Touch: Users will find the IDB easy to use because the touchscreen performance feels similar to their mobile phones or tablets.

• No Dead Zone: Unlike IR touch screens, the display accurately detects touch points at the corners and edges of the display.

Precise Touch Performance1

SoC and LG webOS1

SoC and LG webOS

LG webOS 3.0+ is powered by high-performance System-on-Chip/SOC and can execute several tasks at the same time without the need for a separate media player or PC. Especially when combined with the IDB app, the LG IDB offers both interactive collaboration as well as an intuitive writing application, meaning additional licenses for IDB solution are not required.

IDB App for Efficient Collaboration

The LG IDB app provides users with a convenient and effective meeting experience beyond expectation. Additionally, a virtual meeting space can be created with the IDB, with participation access limited to users who enter a pin number generated by the IDB. Once the participants are in, the meeting session is ready to start.

IDB App for Efficient Collaboration1

#Key_Features__


    • Brightness*
    • 500 cd/m2
    • Screen Size
    • 75”
    • Panel Technology
    • IPS
    • Aspect Ratio
    •
    • Native Resolution
    • 3840 x 2160 (UHD)
    • Viewing Angle (H x V)
    • 178°/178°

AUDIO

    • Built-in Speaker
    • 20 W (10W×2)

CONNECTIVITY

    • Input
    • HDMI (3), DP, DVI-D, RGB, Audio in, USB 3.0, USB 2.0, OPS USB 2.0
    • Output
    • Touch USB 2.0 (2)
    • External Control
    • RS232C in/out, RJ45 in

SPECIAL FEATURES

    • Yes
    • Temperature Sensor, ISM method, DPM Select, Brightness Control, PM Mode, Wake on LAN, Energy Saving, File Play with USB, 2 PIP/PBP, Built-in Wi-Fi (802.11n Combo), USB Cloning, Failover, No Signal Image

KEY FEATURES

    • Yes
    • webOS 3.0+, IDB app, Crestron Connected® Certified, Mirroring, Soft AP, Beacon, Reader Mode, Auto Brightness Sensor, Internal Memory (64GB, System 8GB)

ENVIRONMENTAL CONDITIONS

    • Operating Temperature Range
    • 32 °F to 104 °F
    • Operating Humidity Range
    • 10% ~ 80%

POWER

    • Power Supply
    • 100-240V~, 50/60Hz
    • Power Type
    • Built-In Power
    • Power Consumption-DPM
    • ≤ 0.5 W
    • Power Consumption (Smart Energy Saving)
    • ≤ 170 W
    • Power Consumption-Typ
    • ≤ 240 W

PHYSICAL SPECIFICATIONS

    • Bezel Width
    • 41.6 mm(T/L/R/B)
    • Packed Weight
    • 94 kg
    • Monitor Dimension (W x H x D)
    • 1,732.8 x 1011.1 x 69.7 mm (w/o Handle)
    • Weight (Head)
    • 74.5 kg
    • VESA TM Standard Mount Interface
    • 600 x 400m
    • Carton Dimensions (W x H x D)
    • 1,870 x 1,264 x 285 mm (with pallet)

STANDARD CERTIFICATIONS

    • Safety
    • UL / cUL / CB / TUV / KC
    • EMC
    • FCC Class "A" / CE / KCC

SOFTWARE COMPATIBILITY

    • Content Management Software
    • SuperSign Premium

MEDIA PLAYER COMPATIBILITY

    • OPS Type Compatible
    • Yes

TOUCH

    • Multi touch point
    • Max. 40 Points
    • Protection Glass Thickness
    • 4T (Anti-Glare)
    • Interface
    • USB 2.0
    • Accuracy
    • 2 mm
    • Touch Type
    • P-Cap(Ag Metal Mesh)
    • Available object size for touch
    • more than Ø 6 mm

ACCESSORIES

    • Optional
    • OPS Kit (KT-OPSA), LSW640A/B (Wall Mount)
    • Basic
    • Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Eyebolt (2ea, 86TR3D only), Touch Pen Tip (1ea, TC3D only)
